Here is a downloadable scan of official US Navy hull plans of the 44-gun frigate USS Constitution prepared by the Massachusetts Institute of Technology showing the general appearance of the ship following her 1927 restoration.



The original scan was obtained from the US National Archives and Records Administration, College Park, Maryland.



Click here to search for more ship plans from the US National Archives.



Add to cart and order as if this were a model.  You will be able to download the plans as a *.jpg file after ordering at no cost to you.



Notice: these plans may not print at the scale stated on them due to the scanner settings chosen when the plans were originally scanned.

USS Constitution, 1797, hull plans, 1927 Restoration

SKU: Constitution Hull Plans 1927
$0.00Price
